Type: | Cassette deck |
Basic format: | Closed loop, dual capstan, one way |
Motor: | For capstan: electronic governor DC motor For reel: flat torque DC motor For assist: small DC motor |
Heads: | Recording - Amorphous head Play - Amorphous head Erase - Double gap ferrite head |
Noise Reduction System: | Dolby B / C, dbx Biasing Adjustment Dolby HX Pro (Dynamic) Yamaha ORBiT (static) |
Wow flutter: | ± 0.06% or less (W. Peak, EIAJ) 0.03% or less (W.RMS, JIS) |
Frequency response (EIAJ): | 20Hz to 20kHz ± 3dB (normal) 20Hz to 22kHz ± 3dB (chrome) 20Hz to 24kHz ± 3dB (metal) |
S / N ratio (EIAJ): | 57dB (NR off) 65dB (Dolby B on) 73dB (Dolby C on) 95dB (dbx on) |
Distortion factor: | 0.5% or less |
Power supply: | AC 100V, 50Hz / 60Hz |
Power consumption: | 25W |
Attached: | Wireless remote control RS-K12 |
External dimensions (W x H x D): | 435 × 141 × 379mm |
Weight: | 8.4kg |
Year: | 1988 |
