AKAI X-1800SD
Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco
Type: | Portable Reel to Reel/8 Track Tape Recorder |
Track system: | Reel - 4-track, 2-channel, stereo/monaural system Cartridge - 8-track stereo play back |
Motor: | 2 speed induction |
Equalization: | NARTB |
Tape speeds: | Reel - 1 7⁄8 ips, 3 3⁄4 ips, 7 1⁄2 inch (15 ips with 15 ips adaptor kit) Cartridge - 3 3⁄4 ips |
Tape Speed Deviation: | Within ±3% |
[Wow and flutter] | |
Reel: | Less than 0.18% (7 1⁄2 ips) Less than 0.25% (3 3⁄4 ips) Less than 0.35% (1 7⁄8 ips) |
Cartridge: | Less than 0.35% |
[Frequency response] | |
Reel: | 30Hz to 23kHz (7 1⁄2 ips) 30Hz to 18kHz (3 3⁄4 ips) 30Hz to 9kHz (1 7⁄8 ips) |
Cartridge: | 50 to 15kHz, ±3dB |
Signal to Noise Ratio: | Reel - Better than 50dB Cartridge - Better than 45dB |
[Total Harmonic Distortion] | |
Reel: | Within 2% at 1 ,000Hz 0VU (Line output) Within 5% at 1 ,000Hz 10W (Main output) |
Cartridge: | Within 3% at 1 ,000Hz 0VU |
[Cross-Talk] | |
Reel: | Less than -65dB (Monoural) Less than -43dB (Stereo) |
Cartridge: | Less than -50dB |
Erase Ratio: | Reel - Less than -70dB for all track Cartridge - Less than -65dB |
Inputs: | 60mV (Line) 0.5mV (Mic) |
Output power: | 6W |
Speakers: | 2 x 4" |
Semiconductors: | 20 x Transistors 11 x Diodes |
Power Supply: | AC100 to 240V, 50/60Hz |
Dimensions (W x H x D): | 378 x 338 x 238mm |
Weight: | 17kg |
Year: | 1960 |
